Hey guys! Let's dive into a tricky issue some FreeCAD users are facing. We're talking about a crash that occurs in the expression editor when selecting an item from the dropdown menu. This can be super frustrating, especially when you're deep into your design work. So, let’s break down what’s happening, how to reproduce it, and what might be causing it. We'll also explore potential solutions and workarounds to keep your workflow smooth.

Understanding the Issue

FreeCAD expression editor crashes can really throw a wrench in your design process. The main problem here is that when users are working with expressions and try to select a second-order item from the dropdown in the expression editor, FreeCAD unexpectedly crashes. This issue has been reported and confirmed, so you're not alone if you've experienced this. Let's get into the nitty-gritty details to figure out how to avoid it and what’s causing it.

The Importance of a Stable Expression Editor

Before we go further, it's worth highlighting why the expression editor is such a critical part of FreeCAD. The expression editor allows you to create parametric models, where dimensions and properties are driven by formulas and relationships. This means you can change one value, and the rest of your model updates automatically. For complex designs, this is a huge time-saver and helps ensure accuracy. When the expression editor crashes, it disrupts this entire workflow, making it essential to find a fix.

How to Reproduce the Crash

Okay, so how can you make this crash happen? Knowing the steps is crucial for both understanding the issue and for developers to fix it. Here’s a step-by-step guide to reproduce the crash:

  1. Open the Expression Editor: Start by opening the expression editor for any property of an object in your FreeCAD project. You can usually do this by right-clicking on a property in the Property view and selecting “Expression…”
  2. Select an Object: In the expression editor, begin typing to bring up the auto-completion dropdown. Select an object from the list. This is your starting point.
  3. Trigger Second-Order Auto-Completion: After selecting the object, enter a period (.) followed by a letter. This triggers the auto-completion for the object's properties. For example, if you selected a cube named Cube, you might type .P to trigger properties starting with “P.”
  4. Select a Property: From the suggested properties, select one, such as <<Cube>>.Placement. This is where the crash usually occurs.
  5. Crash!: Boom! FreeCAD crashes. You should see some error messages in the console, which we'll discuss next.

Decoding the Error Messages

When FreeCAD crashes, it usually leaves behind some clues in the form of error messages. In this case, the error messages look something like this:

xdg_surface#91: error 2: the surface already has a role assigned xdg_popup
The Wayland connection experienced a fatal error: Protocol error

These messages indicate that there's an issue with the Wayland connection, specifically related to how surfaces and popups are handled. Wayland is a display server protocol, and these errors suggest that there's a conflict or miscommunication between FreeCAD and the Wayland server. This is a crucial piece of information because it points towards a potential problem in how FreeCAD interacts with the graphical environment.

Technical Details and System Information

To really dig into the problem, it’s essential to know the technical details of the system where the crash is happening. This includes the operating system, FreeCAD version, and other relevant software components. Here’s a breakdown of the typical setup where this issue has been observed:

  • Operating System: NixOS 25.11 (Xantusia) is the OS reported in the original issue, running KDE Plasma on Wayland.
  • FreeCAD Version: The specific version mentioned is 1.0.1.Unknown, but it’s likely that this issue could affect other versions as well.
  • Build Type: Release
  • Python Version: Python 3.13.4
  • Qt Version: Qt 6.9.0
  • Coin: Coin 4.0.3
  • Vtk: Vtk 9.2.6
  • OCC: OCC 7.8.1
  • Graphics Platform: Wayland

Wayland and Its Role

Wayland is a modern display server protocol that is becoming increasingly popular, especially in the Linux world. It's designed to replace the older X Window System (X11) and offers improvements in performance and security. However, Wayland is still relatively new, and compatibility issues can arise, particularly with applications that haven't been fully optimized for it. The error messages we saw earlier directly point to Wayland as a potential source of the problem.

Additional System Information

It's also helpful to look at other system details, such as:

  • Processors: 12 Ă— AMD Ryzen AI 5 340 w/ Radeon 840M
  • Memory: 32 GiB of RAM (30.6 GiB usable)
  • Graphics Processor: AMD Radeon Graphics

This information helps paint a complete picture of the hardware and software environment where the crash is occurring. Knowing the specifics can help developers identify if there are any hardware-specific issues or conflicts.

Potential Causes and Solutions

So, what’s actually causing this crash, and more importantly, how can we fix it? Let’s explore some potential causes and solutions.

Wayland-Related Issues

Given the error messages and the fact that the crash occurs on Wayland, the most likely culprit is a compatibility issue between FreeCAD and Wayland. This could be due to how FreeCAD handles certain graphical operations or how it interacts with the Wayland server. It’s also possible that there are bugs in the Wayland implementation itself.

Possible Solutions:

  • Try X11: A simple workaround is to switch from Wayland to X11, the older display server protocol. This can often resolve compatibility issues. You can usually do this by selecting X11 at the login screen of your desktop environment.
  • Update Graphics Drivers: Make sure your graphics drivers are up to date. Outdated drivers can cause all sorts of issues, especially with newer display protocols like Wayland.
  • FreeCAD Configuration: There might be specific FreeCAD settings that can be tweaked to improve Wayland compatibility. Check the FreeCAD forums and documentation for any recommended settings.

Qt Version Compatibility

FreeCAD uses the Qt framework for its graphical user interface. The version of Qt being used (6.9.0 in this case) could also play a role in the crash. There might be compatibility issues between Qt and Wayland, or even bugs within Qt itself.

Possible Solutions:

  • Try a Different Qt Version: If possible, try running FreeCAD with a different version of Qt. This might involve compiling FreeCAD from source with a specific Qt version.
  • Qt Updates: Keep an eye on Qt updates, as they often include bug fixes and improvements that could address this issue.

FreeCAD Bugs

Of course, there’s always the possibility that the crash is due to a bug within FreeCAD itself. This could be a specific issue in the expression editor or in how FreeCAD handles auto-completion.

Possible Solutions:

  • Update FreeCAD: Make sure you’re running the latest version of FreeCAD. Bug fixes are often included in new releases.
  • Report the Bug: If you’ve confirmed that this is a recurring issue, report it to the FreeCAD developers. The more information you can provide, the better.

Subproject(s) Affected: Expressions

This issue specifically affects the Expressions subproject within FreeCAD. This means that the problem lies within the code responsible for handling expressions and the expression editor. Developers working on this subproject will need to investigate the issue further and implement a fix.

Workarounds and Temporary Solutions

While developers work on a permanent fix, here are some workarounds you can use to minimize the impact of this crash:

  • Avoid Second-Order Auto-Completion: Try to avoid using the auto-completion feature for properties of properties (second-order items). Instead, manually type out the full expression. This can be a bit more time-consuming, but it can help prevent the crash.
  • Save Frequently: Save your work frequently. This is always good advice, but it’s especially important when you’re dealing with a known crash.
  • Use an External Editor: For complex expressions, consider using an external text editor and then pasting the expression into FreeCAD. This can help you avoid the in-app expression editor altogether.

Community and Support

If you’re encountering this issue, remember that you’re not alone! The FreeCAD community is very active and supportive. Here are some resources you can use:

  • FreeCAD Forums: The official FreeCAD forums are a great place to ask questions, share your experiences, and find solutions.
  • GitHub Issues: The FreeCAD GitHub repository is where bugs are reported and tracked. You can search for existing issues related to this crash or create a new one if needed.
  • FreeCAD Wiki: The FreeCAD wiki contains a wealth of information about using FreeCAD, including troubleshooting tips.

Conclusion

The FreeCAD expression editor crash when selecting dropdown items is a frustrating issue, but understanding the problem is the first step towards finding a solution. By reproducing the crash, examining the error messages, and considering potential causes, we can work together to address this bug. Whether it's a Wayland compatibility issue, a Qt problem, or a FreeCAD bug, the community is here to help. So, keep designing, keep experimenting, and let’s make FreeCAD even better!
